3-1 Specifications
3-1-1 General Specifications
All general specifications of the C200H-DA003/DA004 Analog Output Units
conform to those of the C200H, C200HS, and C200HX/HG/HE Series.
3-1-2 Performance Specifications
Item C200H-DA003 C200H-DA004
Number of analog outputs 8
Output signal range (note 1) 0 to 10 V
–10 to 10 V
1 to 5 V
4 to 20 mA
Output impedance 0.5 Ω max. ---
Max. output current 12 mA ---
Max. load resistance --- 600 Ω max.
Resolution 1/4000 (full scale)
Set data 16-bit binary data
Accuracy
23°±2°C
±0.3% of full scale ±0.5% of full scale
(note 2)
0° to 55°C
±0.5% of full scale ±0.8% of full scale
Conversion time (note 3) 1.0 ms/point
Isolation Between input terminals and PC: photocoupler
(No isolation between individual output signals.)
External connectors 28-point terminal block (M3 screws)
Power consumption
100 mA max. at 5 VDC
200 mA max. at 26 VDC 250 mA max. at 26 VDC
Dimensions 34.5 x 130 x 128 (W x H x D) mm (refer to Appendix
A Dimensions)
Weight 450 g max.
Note 1. The output signal range can be set individually for each output.
2. The accuracy is given for full scale. For example, an accuracy of ±0.3%
means a maximum error of ±12 (BCD).
3. This is the time required for converting and outputting the PC data. It takes at
least one cycle for the data stored in the PC to be read by the Analog Output
Unit.
By executing an I/O refresh, the conversion time may be extended by an
additional 0.3 ms approximately.
4. The default setting for the load resistance of the C200H-DA004 is 250 Ω.
When using a load resistance other than 250 Ω, perform the offset and gain
adjustment as required.
