Orion OLM-5510 User Manual

- 76 - - 77 -
ORION
Innitely Expandable
*CheckSum:Execute"Not"operationafteraddingallthevaluesin"STX~Data"area.
3.20. Get Picture Control Data
- Command for acquiring the current Picture Control Data(User Mode, White Balance, Graphic, Video)
- It is available only on Power On (Operative) status.
- The values based on current Color Temp. (Normal Mode / Studio Mode) will be displayed.
- CMD: 0x88
- Send to MLCD
STX CMD Length
Data
ETX
ID Master
Value 0x02 0x88 0x02 Variable 0x01 0x03
*IDrange(Program):0x01(1)~0xFF(255)
*Itisnotapplicableas"Broad-cast"command.
- Receive from MLCD
STX CMD Length
Data
Check Sum ETX
ID Master Control
Value 0x02 0x88 0x36 Variable 0x01 … Variable 0x03
*IDrange(Program):0x01(1)~0xFF(255) 
*Control(52byte)
No. Data Length
Explanation
1 User Mode – Brightness 1 byte Range: 0(0x00) ~ 100(0x64)
2 User Mode – Contrast 1 byte Range: 0(0x00) ~ 100(0x64)
3 User Mode – Sharpness 1 byte Range: 0(0x00) ~ 28(0x1C)
4 Not Used
5 Not Used
6 White Balance – Gain R 1 byte Range: 0(0x00) ~ 255(0xFF)
7 White Balance – Gain G 1 byte Range: 0(0x00) ~ 255(0xFF)
8 White Balance – Gain B 1 byte Range: 0(0x00) ~ 255(0xFF)
9 White Balance – Offset R 1 byte Range: 0(0x00) ~ 255(0xFF)
10 White Balance – Offset G 1 byte Range: 0(0x00) ~ 255(0xFF)
11 White Balance – Offset B 1 byte Range: 0(0x00) ~ 255(0xFF)
12, 13 RGB - Gain R 2byte Range : 0(0x000) ~ 1023(0X3FF)
14, 15 RGB - Gain G 2byte Range : 0(0x000) ~ 1023(0X3FF)
16, 17 RGB - Gain B 2byte Range : 0(0x000) ~ 1023(0X3FF)
18, 19 RGB - Offset R 2byte Range : 0(0x000) ~ 1023(0X3FF)
20, 21 RGB - Offset G 2byte Range : 0(0x000) ~ 1023(0X3FF)
22, 23 RGB - Offset B 2byte Range : 0(0x000) ~ 1023(0X3FF)
24 ~ 47 Not Used 24bt ye
48 Video Brightness 1byte Range : 0(0x00) ~ 255(0xFF)
49 Video Contrast 1byte Range : 0(0x00) ~ 255(0xFF)
50 Video Color 1byte Range : 0(0x00) ~ 255(0xFF)
51 Dimming 1byte Range : 0(0x00) ~ 100(0x64)
52 Gamma 1byte Range : 1(0x01) ~ 6(0x06)
3.21. Auto Calibration
- Command for synchronizing the ADC Gain and Offset for 16-Gray input. It is available only for PC.
- It is available only on Power On (Operative) status.
- CMD : 0x80
- Send to MLCD
A. NormalCommand
STX CMD Length
Data
ETX
ID Master
Value 0x02 0x80 0x02 Variable 0x01 0x03
B. BroadcastCommand
STX CMD Length Data: ID ETX
Value 0x02 0x80 0x01 0x00 0x03
*IDrange(Program):0x01(1)~0xFF(255)
*Broadcast:AllLCDsetswillexecutethesamecommand,whentheIDis0x00.Noresponse(Onewaycommand)
- Receive From MLCD
STX CMD Length
Data
Check Sum ETX
ID Master
Value 0x02 0x80 0x02 Variable 0x01 Variable 0x03
3.22. Dimming Control
- Command for adjusting the Back-Light Brightness.
- CMD : 0xDC
- Send to MLCD
A. Normalcommand
STX CMD Length
Data
ETX
ID Master Control
Value 0x02 0xDC 0x03 Variable 0x01 Variable 0x03
*IDRange(Program):0x01(1)~0xFF(255)
*Control:0x00(0)~0x64(100)
B. Broadcastcommand
STX CMD Length
Data
ETX
ID Control
Value 0x02 0xDC 0x02 0X00 Variable 0x03
*MakeallLCDdothesameoperation.But,therewillbenoreturncommunication.(Onewaycommand)
- Receive From MLCD
STX CMD Length
Data
Check Sum ETX
ID Master
Value 0x02 0xDC 0x02 Variable 0x01 Variable 0x03
*CheckSum:execute"Not"operationafteraddingallthevaluesin"STX~Data"area.
3.23. Gamma Control
- Command for adjusting the Gamma.
- CMD : 0x89
MLCD
