55
CLEAR LOG
BACK TOTL DAILY
Are you sure?
NO YES
Today 0000Ah 00.0 KWH
011Vp 00.0Ap 0.00kWp
MAX 14.7V ABS 01:00
MIN 14.6V FLT 00:00
Today 0000Ah 00.0 KWH
011Vp 00.0Ap 0.00kWp
MAX 14.7V ABS 01:00
MIN 14.6V FLT 00:00
A user can clear either the daily or accumulated statistics
of the Charge Controller by pressing the second button
from the left in this screen. This will bring up the CLEAR
LOG screen.
The CLEAR LOG screen o ers the option of clearing up
to 128 days of accumulated statistics or the total in the
secondary STATS screen (page 56). Press and hold either
the <TOTL> (total) or <DAILY >key to clear those speci c
statistics.
The Are you sure? screen appears. Pressing the <YES> soft
key returns to the CLEAR LOG screen; pressing the <NO>
soft key returns to the Logging screen.
Pressing the third and fourth soft keys changes the
displayed day’s statistics, by moving either forward or
backward within the 128 days of available statistics that
are viewable.
NOTE: If two or more Charge Controllers are used in the
same system and are started up or cleared on di erent
days, their numeric dates will not be the same. This can
lead to some misunderstandings when looking back and
comparing data between the two or more units. A user
looking back at day 12 on both units would nd very
di erent results.
15. Logging
