Outback Power Systems FLEXMAX 80 User Manual

24
PB
AUX MODE Menu Path
To access the AUX Output Menu:
• Press the rst soft key once from the STATUS Menu to open the MAIN Menu.
• Press either of the arrow soft keys until the “
g” is to the left of Aux.
• Press the
<GO> soft key. If more than ten minutes have passed since any activity, the PASSWORD
screen becomes active, requiring the user to input the 141 PASSWORD and press < ENTER>.
• Pressing the <NEXT> soft key scrolls through the AUX functions.
• The most commonly used AUX modes are Vent Fan, Low Battery Disconnect and Diversion.
g Charger Aux Light
EQ Misc Advance
Logging Stats
EXIT f g GO
Charger gAux Light
EQ Misc Advance
Logging Stats
EXIT
f g GO
AUX MODE
Vent Fan
Output: Off Off
EXIT NEXT SET MODE
PASSWORD
***150***
ENTER - +
AUX MODE
Vent Fan
Output: Off Off
EXIT NEXT SET MODE
g g
AUX MODE
Remote
Output: Off Off
EXIT NEXT SET MODE
AUX MODE
Vent Fan
Output: Off Off
EXIT NEXT SET MODE
AUX MODE
PV Trigger
Output: Off Off
EXIT NEXT SET MODE
AUX MODE
ERROR OUTPUT
Output: Off Off
EXIT NEXT SET MODE
AUX MODE
Night Light
Output: Off Off
EXIT NEXT SET MODE
AUX MODE
Float
Output: Off Off
EXIT NEXT SET MODE
AUX MODE
Diversion: Relay
Output: Off Off
EXIT NEXT SET MODE
AUX MODE
Diversion: Solid St
Output: Off Off
EXIT NEXT SET MODE
AUX MODE
Low Batt Disconnect
Output: Off Off
EXIT NEXT SET MODE
g g
g
g
g
g
g
g
g
g
