Outback Power Systems FLEXMAX 80 User Manual

40
PB
Auto (default) leaves backlight and soft keys on for
up to nine minutes whenever any soft key is pressed
(pressing any soft key when the LCD is not lighted
does not change any settings). Minutes are adjustable
using the < -> and < + > soft keys.
On or O states are also available.
Press the <EXIT> soft key twice to return to the MAIN
Menu screen
Press the < > soft key to move the “ g “ to the EQ
option. When the g is to the left of EQ, press the
<GO> soft key.
Charger Aux gLight
EQ Misc Optimize
Logging Stats
EXIT
f g GO
BACKLIGHT CONTROL
Auto Time 2 Minutes
Auto
EXIT - + MODE
On
O
Auto
10. Backlight
11. EQ—Battery Equalize
The intent of an equalization charge is to bring all battery cells to an equal voltage. Sealed batteries
should not be equalized unless specically instructed by the manufacturer. Shut o or minimize all
loads on the battery. When equalizing, be sure the EQ voltage will not damage any still energized DC
load. If possible, ensure the EQ cycle starts and stops the same day it is initiated or unnecessary battery
gassing will occur.
• Occasional equalization extends the life of ooded electrolyte batteries.
• Proceed with caution! A vent fan is recommended in enclosed spaces.
• The FLEXmax 80 allows the user to set voltages and times of equalization process.
• Both manual and auto modes are available.
• EQ voltage is
not battery temperature compensated.
•
Always check the electrolyte level in the batteries before and after equalizing.
