Outback Power Systems FLEXMAX 80 User Manual

49
PB
ADVANCED MENU
Absorb End Amps
00 A
EXIT NEXT - +
ADVANCED MENU
Rebulk Voltage
12.6 V
EXIT NEXT - +
An Absorb charge cycle normally ends when a battery
voltage is maintained at the Absorb set point for the user-
determined time period. Use the < -> or
< + >
soft keys to adjust the Absorb End Amps to an
optimal value (the default value is 00). While the battery
voltage is at or above the Absorb target and the Absorb
End Amps value is reached for a time delay of 15 seconds,
the FLEXmax 80 will switch to the Float stage regardless
of the charger time minutes as shown in the Misc menu
under ChgT. The charger timer will be cleared. This is an
optional set point and is used for few installations.
When nished with any adjustments, press the <NEXT>
soft key to view the Rebulk Voltage screen.
In Float, if the battery voltage falls below the ReBulk
Voltage set point for at least 90 seconds, the FLEXmax
80 will automatically reinitiate a Bulk charge cycle. The
default is set to 6 volts, a very low value that will disable
this function. The Rebulk Voltage value can be adjusted by
pressing the < - > or < + > soft keys. Press the <NEXT>
soft key to view the Vbatt Calibration screen.
Figure 6 NOTE: In BULK, the FLEXmax 80 will charge as long as necessary to complete the
cycle, regardless of the timer’s set points
