MATE-Displayed FLEXmax 80 Status Meter Screens
FLEXmax METER Screens
• mode/pv/in/bat/out: displays the charger mode, the PV array voltage, the incoming PV amps, the
battery voltage, and the outgoing amps to the battery
•
charger watts: charger output measured in watts
•
charger kwhrs: kilowatt hours produced today by the FLEXmax 80
•
charger amps dc: the amount of amperage the FLEXmax 80 is sending to the battery
•
battery voltage: current battery voltage
•
panel voltage: current voltage from the PV array
mode: Silent P02
in 10.2 vdc 0 adc
out: 13.4 vdc 0 adc
DOWN STATUS PORT
STATUS/CC/METER--------P02
charger 0 w
watts
DOWN UP TOP PORT
STATUS/CC/METER-----P02
charger 0.0 kwh
kwhrs
DOWN UP TOP PORT
STATUS/CC/METER-------P02
charger +000 adc
amps dc
DOWN UP TOP PORT
STATUS/CC/METER---------P02
battery 13.5 vdc
voltage
DOWN UP TOP PORT
STATUS/CC/METER--------P02
panel 10.2 vdc
voltage
DOWN UP TOP PORT
STATUS/CC/METER-----
end of meter menu
UP TOP STATUS
STATUS/CC/PAGE 1-------------
MODE METER SETP PG2
g g
g
g
g
Press <SETP> to view the
SETPOINT screens
STATUS/CC/METER---------P02
CC rmware revision
001.008.009
DOWN UP TOP PORT
