Owon XDM Series User Manual

2.Quick Start
11
Power On
(1) Connect the instrument to the AC supply using the supplied power cord.
Warning:
To avoid electric shock, the instrument must be grounded properly.
(2) Press down the power button at the front panel, the screen shows the boot screen.
Measurement Connections
After selecting the desired measurement function, please connect the signal (device)
under test to the multimeter according to the method below. To avoid instrument
damage, do not discretionarily switch the measurement function when measuring.
DC Voltage Measurement
DC Voltage
AC Voltage Measurement
AC Voltage
DC Current Measurement
DC Current
AC Current Measurement
AC Current
2-wire Resistance Measurement
I
2-wire Resistance
4-wire Resistance Measurement
I
4-wire Resistance
