Port Configuration
You can configure the port parameters in port configuration.
Serial
Press the front panel key, press the Serial softkey to access the serial port setting
menu.
Press the Baud softkey to select the desired baud rate from 1200, 2400, 4800, 9600,
19200, 38400, 57600 or 115200. The default is 9600. Make sure that the baud rate
matches that of the computer.
Press the Data bits softkey, select the data bits from 5, 6, 7, 8.
Press the Odd-Even softkey, select the parity from None, Odd or Even. The default is
None.
Press the Stop bit softkey, select the stop bit from 1, 2.
Trigger
See page 28, Triggering.
Output
Press the front panel key, press the Output softkey to access the output setting
menu.
Press the Output softkey to configure the output of the [AUX Output] connector at the
rear panel.
VMComp
Defaults to Voltmeter Measurement Complete Output, outputs a pulse whenever the
multimeter finishes taking a measurement to allow you to signal other devices.
Press the VMC Out softkey to set the edge slope of the voltmeter complete output.
P/F
The [AUX Output] connector can be configured to output a pulse when the limits are
exceeded in Math limits function.
Net Type
Press the front panel key, press the NET Type softkey to select Off, LAN etc.
LAN
Press the LAN Setting softkey, set the IP address, subnet mask, gateway, port.
Press to move the cursor, press to increase or decrease the value. Restart
the instrument for the parameter changes to take effect.
Contact your LAN administrator for the LAN setting details.
