Owon XDM Series User Manual

3.Functions and Operations
29
softkey, press to move the cursor, press to increase or decrease the value.
The range is 1 to 999,999.
External Trigger
Press the front panel key, press the Trigger softkey, press the Source softkey to
select External. When External trigger is used, the multimeter receives the trigger pulse
from the [Ext Trig] connector at the rear panel, triggers at the specified edge of the pulse
signal and acquires measured data.
 Auto delay is applied for external trigger, the instrument automatically determines the
delay based on function, range and measurement speed.
 When using external trigger, you can set the edge type for the pulse from the [Ext Trig]
connector at the rear panel. The multimeter will trigger on the specified type of edge.
Press the Trg Edge softkey to select Rising or Falling.
