1. Before Use
1
Mode dial (P42)
2
Shutter button (P40)
3
Camera ON/OFF switch (P36)
4
Self-timer indicator (P175)/
AF Assist Lamp (P151)
5
Focus mode dial (P139, 153)
6
Stereo microphone (P225)
• Be careful not to cover the microphone with
your finger. Doing so may make sound
difficult to record.
7
Hot shoe (Hot shoe cover) (P203)
• Keep the Hot Shoe Cover out of reach of
children to prevent swallowing.
8
Focus distance reference mark (P156)
9
Diopter adjustment lever (P37)
10
Status indicator (P36)/
Wi-Fi
®
connection lamp (P258)
• The lamp lights green when the camera is
turned on, and lights blue when it is
connected to Wi-Fi.
11
Lens fitting mark (P33)
12
Sensor
13
Mount
14
Lens lock pin
15
Lens release button (P32)
16
Speaker
• Be careful not to cover the speaker with your
finger. Doing so may make sound difficult to
hear.
17
Shoulder strap eyelet (P20)
To Next Page
