Panduit PANTHER LS8E User Manual

CREATING DATA LISTS
22
The Data Tool
The data tool is used to create printable data lists in the PANTHER™ LS8E. The
data tool is very useful for customizing labels because it allows up to one hundred
unique labels to be created from a list of data. With the data tool, users can input,
store, or transfer custom lists of data. Data lists can be created directly on the
LS8E printer or imported from Microsoft Excel. The P
ANTHER™ LS8E stores up to
4 unique data lists.
Creating a Data Tool
The data tool should be accessed from the home screen. To access the data
tool:
1. Press the INSERT
key to enter the tools menu.
2. Press the directional arrows to highlight the data tool.
3. Press the
key to select the data tool.
4. Use the up or down directional arrow keys to highlight the data tool options.
You can recall a previously saved data list or you can create a new list.
Creating a new list is similar to working on the home screen. Use the PAGE
function to move forward or backward through the 100 data list items. After
working in list, press the F5 key to exit the list. Follow the onscreen
instructions to Save, Discard, or Continue Editing.
5. After making all changes to the data tool options, select Save and Exit and
then press the
key to accept all of the changes and to return to the
home screen. Otherwise, press the DEL key to return to the home screen
without accepting changes.
6. On the home screen, the data tool icon
will appear at the position of the
cursor.
Creating a Data Tool with Microsoft Excel
See page 43 for detailed instructions
Editing a Data Tool
To edit a data tool on the home screen, move the cursor directly to the left of the
data tool so that the icon is highlighted. Press the SHIFT key and then press the
INSERT key. Follow the steps list above for creating a data tool.

Panduit PANTHER LS8E Specifications

Printing Specifications

print method	Thermal transfer
effective print width	1.00” (25.4 mm)
print length	12.00” (maximum label length)
print resolution	203 dpi (horizontally and vertically)
label width	0.24” to 1.0”
media length	Up to 25’ continuous tapes

Display

display	4 line x 14 graphic LCD with backlight
lcd contrast control	Adjustable via keypad

Power

power supply	6 AA alkaline batteries
ac adapter	Universal Input (100 - 240 VAC, 50/60 Hz)

Operating Environment

operating temperature	41-104° F (5-40 °C)
operating humidity	0 - 90% relative humidity (non-condensing)
storage temperature	-40-140° F (-40-60 °C)
storage humidity	0 - 90% relative humidity (non-condensing)

Weight and Dimensions

weight	1.76 lbs. (0.80 kg)
