SETTING UP THE PANTHER LS8E
AND USING FILE MANAGER
33
The P
ANTHER™ LS8E has the ability to store and recall label files. Label
files are stored and recalled within File Manager. Label files are
designated with a .LS8 ending.
To access the File Manager, press the SHIFT key and then press the PAGE key:
1. Use the right or left directional arrow keys to select the desired file. There
are 50 file storage locations in the P
ANTHER™ LS8E.
NOTE: When saving a new file, press the
key to begin entering a
file name. Use the alphabetic or numeric keys to enter a file
name. After entering a file name, press the
key again to
Save.
NOTE: When renaming a previously saved file, press the
key to
begin entering the new file name. Use the alphabetic or
numeric keys to enter the new file name. After entering the
name, press the
key again to Save. .
2. Use the up or down directional arrow keys to highlight Action.
3. Use the right or left directional arrow keys to select Save, Load, Delete, or
Delete All.
WARNING: Selecting Delete All will erase all stored labels.
4. Press the
key to complete the selected action.

Panduit PANTHER LS8E Specifications

Printing Specifications

print method	Thermal transfer
effective print width	1.00” (25.4 mm)
print length	12.00” (maximum label length)
print resolution	203 dpi (horizontally and vertically)
label width	0.24” to 1.0”
media length	Up to 25’ continuous tapes

Display

display	4 line x 14 graphic LCD with backlight
lcd contrast control	Adjustable via keypad

Power

power supply	6 AA alkaline batteries
ac adapter	Universal Input (100 - 240 VAC, 50/60 Hz)

Operating Environment

operating temperature	41-104° F (5-40 °C)
operating humidity	0 - 90% relative humidity (non-condensing)
storage temperature	-40-140° F (-40-60 °C)
storage humidity	0 - 90% relative humidity (non-condensing)

Weight and Dimensions

weight	1.76 lbs. (0.80 kg)
