Panduit PANTHER LS8E User Manual

GENERAL SPECIFICATIONS
66
Print Method: Thermal transfer
Effective Print Width: 1.00” (25.4 mm)
Print Length: 12.00” (maximum label length)
Print Resolution: 203 dpi (horizontally and vertically)
Label Width: 0.24” to 1.0”
Media Length: Up to 25’ continuous tapes
Media Types: Die cut or continuous tapes
Materials: Vinyl self-laminating, flattened heat shrink,
vinyl cloth, polyester, continuous tape, vinyl,
non-adhesive polyester, polyolefin
Media Cutting: Manually operated cutter
Display: 4 line x 14 graphic LCD with backlight
LCD Contrast Control: Adjustable via keypad
Operating System: Panduit proprietary – user upgradeable
Power Supply: 6 AA alkaline batteries
AC Adapter: Universal Input (100 - 240 VAC, 50/60 Hz)
Oper. Temp/Hum: 41-104° F (5-40 °C),
0 - 90% relative humidity (non-condensing)
Stor. Temp/Hum: -40-140° F (-40-60 °C),
0 - 90% relative humidity (non-condensing)
Compliance: FCC Part 15 Class A
European Community EMC and Low Voltage Directives
regarding safety, emissions, and immunity
European Community Restriction of Hazardous
Substances (RoHS)
European Community Waste Electrical and Electronic
Equipment (WEEE)
Weight 1.76 lbs. (0.80 kg)

Panduit PANTHER LS8E Specifications

Printing Specifications

print method	Thermal transfer
effective print width	1.00” (25.4 mm)
print length	12.00” (maximum label length)
print resolution	203 dpi (horizontally and vertically)
label width	0.24” to 1.0”
media length	Up to 25’ continuous tapes

Display

display	4 line x 14 graphic LCD with backlight
lcd contrast control	Adjustable via keypad

Power

power supply	6 AA alkaline batteries
ac adapter	Universal Input (100 - 240 VAC, 50/60 Hz)

Operating Environment

operating temperature	41-104° F (5-40 °C)
operating humidity	0 - 90% relative humidity (non-condensing)
storage temperature	-40-140° F (-40-60 °C)
storage humidity	0 - 90% relative humidity (non-condensing)

Weight and Dimensions

weight	1.76 lbs. (0.80 kg)
