CREATING FRAMES
28
Frames
Frames are useful for customizing a label. There are three unique frame settings
available: Box, Reverse, and Box Off.
The Box setting places a box outline around the perimeter of the entire label area.
The Reverse setting places a dark background with light text characters on a
label.
The Box Off setting deactivates the frame.
Creating a Frame
The frame menu should be accessed from the home screen. To access the box
tool:
1. Press the SHIFT key and then press the LINE key to enter box menu.
2. Use the right directional arrow key to change the setting.
3. Press the
key to select the frame type.
4. On the home screen, the frame icon
will appear on the right side of the
display when a frame is activated.
NOTE: If a frame is activated, it will appear on all printed pages of a
label.
WARNING
WARNING

Panduit PANTHER LS8E Specifications

Printing Specifications

print method	Thermal transfer
effective print width	1.00” (25.4 mm)
print length	12.00” (maximum label length)
print resolution	203 dpi (horizontally and vertically)
label width	0.24” to 1.0”
media length	Up to 25’ continuous tapes

Display

display	4 line x 14 graphic LCD with backlight
lcd contrast control	Adjustable via keypad

Power

power supply	6 AA alkaline batteries
ac adapter	Universal Input (100 - 240 VAC, 50/60 Hz)

Operating Environment

operating temperature	41-104° F (5-40 °C)
operating humidity	0 - 90% relative humidity (non-condensing)
storage temperature	-40-140° F (-40-60 °C)
storage humidity	0 - 90% relative humidity (non-condensing)

Weight and Dimensions

weight	1.76 lbs. (0.80 kg)
