PRINTER TROUBLESHOOTING
62
SYMPTOM ACTION
Printed image is full,
but grayish or
“translucent”.
• Print head heat setting is too high. Reduce heat
setting. The heat setting is accessible in the Setup
menu. Press the SETUP key, scroll down to heat
and Press ENTER. Adjust the heat setting with the
up or down arrows.
Voids in printed
image: areas where
there is no print.
• Print head elements or “dots” are dirty or obstructed.
Clean print head with soft-stemmed swab and
isopropyl alcohol.
LABELS
Labels not
registering
• Make sure that labels are feeding properly.
• Printer not reset for new label format. Turn printer
OFF, then ON again. Printer will re-calibrate for new
label.
Die-cut labels
continue to feed
without stopping.
• Label sensor is dirty or obstructed. Clean sensor
with soft-stemmed swab and isopropyl alcohol or
compressed air.
CUTTER
Cutter does not work
• Make sure that cutter blade and print head are free
of debris or adhesive build-up. See detailed
cleaning instructions for more information.
DISPLAY
Printer powers on
but nothing appears
on the display
• Hold F5 and power the printer on. Reinstall printer
firmware using PanTherLink software and a USB
cable.

Panduit PANTHER LS8E Specifications

Printing Specifications

print method	Thermal transfer
effective print width	1.00” (25.4 mm)
print length	12.00” (maximum label length)
print resolution	203 dpi (horizontally and vertically)
label width	0.24” to 1.0”
media length	Up to 25’ continuous tapes

Display

display	4 line x 14 graphic LCD with backlight
lcd contrast control	Adjustable via keypad

Power

power supply	6 AA alkaline batteries
ac adapter	Universal Input (100 - 240 VAC, 50/60 Hz)

Operating Environment

operating temperature	41-104° F (5-40 °C)
operating humidity	0 - 90% relative humidity (non-condensing)
storage temperature	-40-140° F (-40-60 °C)
storage humidity	0 - 90% relative humidity (non-condensing)

Weight and Dimensions

weight	1.76 lbs. (0.80 kg)
