Panduit PANTHER LS8E User Manual

PRINTER CLEANING INSTRUCTIONS
59
Cleaning the Print head and Drive Roller
The LS8E printer is cleaned using the LS8-CLN cleaning kit.
The print head should be cleaned regularly, and more often in harsh
environments. The print head should be cleaned whenever any irregular printing
results occur. The drive roller should be cleaned whenever foreign matter, such
as dust or adhesive, is present.
1. Turn OFF power to printer.
2. Remove the cassette door.
3. Unlock the print head latch.
4. Remove the label cassette from the printer
5. Rub a cotton swab with cleaning solution along the print head.
6. Repeat until no more residue is picked up by the swab.

Panduit PANTHER LS8E Specifications

Printing Specifications

print method	Thermal transfer
effective print width	1.00” (25.4 mm)
print length	12.00” (maximum label length)
print resolution	203 dpi (horizontally and vertically)
label width	0.24” to 1.0”
media length	Up to 25’ continuous tapes

Display

display	4 line x 14 graphic LCD with backlight
lcd contrast control	Adjustable via keypad

Power

power supply	6 AA alkaline batteries
ac adapter	Universal Input (100 - 240 VAC, 50/60 Hz)

Operating Environment

operating temperature	41-104° F (5-40 °C)
operating humidity	0 - 90% relative humidity (non-condensing)
storage temperature	-40-140° F (-40-60 °C)
storage humidity	0 - 90% relative humidity (non-condensing)

Weight and Dimensions

weight	1.76 lbs. (0.80 kg)
