Panduit PANTHER LS8E User Manual

LABELING EXERCISES
49
Exercise 1
Create basic text on a self-laminating wire/cable label
• Step 1: Insert a self-laminating label cassette such as S100X150VAC
• Step 2: When prompted, select New Blank File. Save previous label if
necessary.
• Step 3: Type 1234
• Step 4: Press PRINT
Results:
Exercise 2
Create basic text on heat shrink tubing
• Step 1: Insert a heat shrink tubing label cassette such as H000X044F1C
• Step 2: When prompted, select New Blank File. Save previous label if
necessary.
• Step 3: Type ABCD
• Step 4: Press PRINT
Results:
1234
1234
1234
Hint: S100X150VAC defaults to 10
point font printed in Wire Marker
Mode.
You can adjust the font size by
pressing the SIZE key.
You can adjust the label mode by
pressing the LABEL key.
ABCD
ABCD
ABCD
Hint: H000X044F1C defaults to 10 point
font printed in Wire Marker Mode with
an “Auto” length setting.
You can adjust the font size by
pressing the SIZE key.
You can adjust the label mode by
pressing the LABEL key. For
example, try Tape Mode.
You can set a fixed tubing length by
using the LENGTH function. For
exam
p
le, enter 200 for 2.00 inches

Panduit PANTHER LS8E Specifications

Printing Specifications

print method	Thermal transfer
effective print width	1.00” (25.4 mm)
print length	12.00” (maximum label length)
print resolution	203 dpi (horizontally and vertically)
label width	0.24” to 1.0”
media length	Up to 25’ continuous tapes

Display

display	4 line x 14 graphic LCD with backlight
lcd contrast control	Adjustable via keypad

Power

power supply	6 AA alkaline batteries
ac adapter	Universal Input (100 - 240 VAC, 50/60 Hz)

Operating Environment

operating temperature	41-104° F (5-40 °C)
operating humidity	0 - 90% relative humidity (non-condensing)
storage temperature	-40-140° F (-40-60 °C)
storage humidity	0 - 90% relative humidity (non-condensing)

Weight and Dimensions

weight	1.76 lbs. (0.80 kg)
