3.2 Overview of encoder classes – functionality
Model number Cyclic data exchange Adjustable parameters Other items
Class 1
singleturn
position value – 16-bit input direction of rotation -
Class 1
multiturn
position value – 32-bit input direction of rotation -
Class 2
singleturn
position value – 16-bit input
preset value – 16-bit output
direction of rotation
scaling
preset function
Class 2
multiturn
position value – 32-bit input
preset value – 32-bit output
direction of rotation
scaling
preset function
P+F 2.1
singleturn
position value (32-bit input)
preset value/TEACH-IN
(32-bit output)
direction of rotation
scaling
gear factor
reduced diagnostics
limit switch
preset function
commissioning
mode
P+F 2.1
multiturn
position value (32-bit input)
preset value/TEACH-IN
(32-bit output)
direction of rotation
scaling
gear factor
reduced diagnostics
limit switch
preset function
commissioning
mode
P+F 2.2
singleturn
position value (32-bit input)
preset value/TEACH-IN
(32-bit output)
speed
(16-bit input)
direction of rotation
scaling
gear factor
reduced diagnostics
limit switch
unit of speed output
preset function
commissioning
mode
speed output
P+F 2.2
multiturn
position value (32-bit input)
preset value/TEACH-IN
(32-bit output)
speed
(16-bit input)
direction of rotation
scaling
gear factor
reduced diagnostics
limit switch
unit of speed output
preset function
commissioning
mode
speed output
