Absolute rotary encoder P**58
Technical data
Subject to reasonable modifications due to technical advances. Copyright Pepperl+Fuchs, Printed in Germany
Pepperl+Fuchs Group • Tel.: Germany +49 621 776-0 • USA +1 330 4253555 • Singapore +65 67799091 • Internet http://www.pepperl-fuchs.com
Date of issue 01/15/04
36
8 Technical data
8.1 Electrical data
8.2 Mechanical data
General design
based on DIN VDE 0160, protection class III, accumulation level 2,
overvoltage category II
Power supply 10 V DC ... 30 V DC (absolute limit values)
Power consumption max. 2.5 Watt
EMC
emitted interference in accordance with EN 61000-6-4
interference rejection in accordance with EN 61000-6-2
Bus interface galvanically isolated by optocoupler
Interface line driver in accordance with RS 485
Baud rates
12 MBaud; 6 MBaud; 3 MBaud; 1.5 MBaud; 500 kBaud;
187.5 kBaud; 93.75 kBaud; 19.2 kBaud; 9.6 kBaud
Resolution
standard: 8.192 steps/revolution
optional: 65,536 steps/revolution
Number of revolutions
recorded
standard: 4,096 revolutions
optional: 16,384 revolutions
Spacing accuracy ± 2 LSB at 16 bits, ± 1 LSB at 13 bits, ± 0,5 LSB at 12 bits
Step frequency max. 100 kHz
Code type binary code
Expected service life,
electrical
> 10
5
h
Addressing adjustable via rotary switch in connection hood
Absolute rotary encoders must only be operated at low protective
voltage.
Housing aluminium or stainless steel
Flange servo flange clamping flange
Shaft diameter 6 mm 10 mm
Shaft length 10 mm 20 mm
Shaft load axial 40 N, radial 110 N
Moment of friction ≤ 3 Ncm
Moment of inertia of the rotor
≈ 30 gcm
2
Expected service life
> 10
5
h for 1000 min
-1
Speed
max. 12,000 min
-1
Shock (EN 60068-2-27) ≤ 100 g, 6 ms
Vibration (EN 60068-2-6) ≤ 10 g, 10 Hz ... 2000 Hz
Connection connection hood with terminal strip as T distributor
Weight (including connection hood)
singleturn
multiturn
aluminium: ca. 550 g
stainl. steel: ca. 1.100 g
aluminium: ca. 600 g
stainl. steel: ca. 1.200 g
