Absolute rotary encoder P**58
Diagnostic messages
Subject to reasonable modifications due to technical advances. Copyright Pepperl+Fuchs, Printed in Germany
Pepperl+Fuchs Group • Tel.: Germany +49 621 776-0 • USA +1 330 4253555 • Singapore +65 67799091 • Internet http://www.pepperl-fuchs.com
Date of issue 01/15/04
27
6 Diagnostic messages
6.1 Overview
In the "DDLM_Slave_Diag" operating mode, diagnostic data is transferred from the
rotary encoder to the master on request. The number of diagnostic bytes is 57.
Exception: Reduced diagnostics (see section 5.1.5). Output of diagnostic data is
based on the specifications of the PROFIBUS standard (Octets 1 ... 6) or on the
encoder profile (starting at Octet 7).
Diagnostic function Data type
Diagnostic
Octet
number
Encoder class
Station status 1 (see: PROFIBUS standard) Octet 1 1
Station status 2 (see: PROFIBUS standard) Octet 2 1
Station status 3 (see: PROFIBUS standard) Octet 3 1
Diagnostic master address Octet 4 1
Profibus user organisation ID number Octet 5, 6 1
Advanced diagnostics header Octet string 7 1
Alarm messages Octet string 8 1
Operating status Octet string 9 1
Encoder type Octet string 10 1
Resolution per revolution (hardware) unsigned 32 11 ... 14 1
Number of revolutions (hardware) unsigned 16 15, 16 1
Additional alarm messages Octet string 17 2
Supported alarm messages Octet string 18, 19 2
Warning messages Octet string 20, 21 2
Supported warning messages Octet string 22, 23 2
Profile version Octet string 24, 25 2
Software version Octet string 26, 27 2
Operating time unsigned 32 28 ... 31 2
Reference point shift unsigned 32 32 ... 35 2
Manufacturer specific: offset values unsigned 32 36 ... 39 2
Resolution per revolution as assigned by
parameter
unsigned 32 40 ... 43 2
Overall resolution as assigned by parameter unsigned 32 44 ... 47 2
Serial number ASCII string 48 ... 57 2
