Pepperl+Fuchs P 58 Series User Manual

Absolute rotary encoder P**58
Appendix
Subject to reasonable modifications due to technical advances. Copyright Pepperl+Fuchs, Printed in Germany
Pepperl+Fuchs Group • Tel.: Germany +49 621 776-0 • USA +1 330 4253555 • Singapore +65 67799091 • Internet http://www.pepperl-fuchs.com
Date of issue 01/15/04
41
9Appendix
9.1 Type code, model number
P 58 – AGR0BN–1213
Number of bits singleturn
13 8,192 (standard)
16 65,536
Number of bits multiturn
12 4,096 (standard)
14 16,384
Option 2
N not extended
Output code
B binary
Option 1
0 no option
Exit position
R radial
Connection type
AG removable housing cover with terminal compartment
Shaft dimension/flange version
011 shaft Ø10 mm x 20 mm with clamp flange
032 shaft Ø6 mm x 10 mm with servo flange
F1A recessed hollow shaft Ø10 mm x 30 mm
F2A recessed hollow shaft Ø12 mm x 30 mm
Housing material
N Aluminium, powder-coated
I Inox
Principle of operation
M multiturn
S singleturn
Shaft version
S recessed hollow shaft
V solid shaft
Data format
P PROFIBUS
