Pepperl+Fuchs P 58 Series User Manual

Absolute rotary encoder P**58
Technical data
Subject to reasonable modifications due to technical advances. Copyright Pepperl+Fuchs, Printed in Germany
Pepperl+Fuchs Group • Tel.: Germany +49 621 776-0 • USA +1 330 4253555 • Singapore +65 67799091 • Internet http://www.pepperl-fuchs.com
Date of issue 01/15/04
38
8.4 Dimensional drawings
8.4.1 Rotary encoder with servo flange
Singleturn design
Multiturn design
3 x M4
6 deep
Servo flange
Cable gland PG9, radial
10
3 x 120˚
23
30
~32
ø59
4
82
ø58
ø50f7
ø6f6
3 3
ø60
ø42
63.5
15
ø5.5 ... ø9
20 20
3 x M4
6 deep
Servo flange
Cable gland PG9, radial
10
3 x 120˚
23
30
~32
ø59
4
92
ø58
ø50f7
ø6f6
3 3
ø60
ø42
63.5
15
ø5.5 ... ø9
20 20
