Philips 32PHS4131/12 - Cable Dressing (49 4131 Series)

Mechanical Instructions
EN 12 TPN16.3E LA4.
2016-Oct-28
back to
div. table
Figure 4-6 Cable dressing (49" 4131 series)
20210_105.eps
CN601
CN401
CN8101
CN9301
CN701
CN408
MAIN POWER SUPPLY
(1054)
A
IR/LED BOARD
(1056)
J
SSB
(1053)
B
ECN701
ECN601
ECN401
ECN408
ECN408
ECN401
ECN601
LOUDSPEAKER
(1184)
LOUDSPEAKER
(1184)
CN201
KEYBOARD CONTROL (1057)
E
CN01
