Alignments
EN 30 TPN16.3E LA6.
2016-Oct-28
back to
div. table
This group setting of colour temperature will be applied
automatically to the TV / VGA / HDMI / AV sources.
Note: The information of the RGB value is only for reference,
the specific value is based on model adjustment.
6.4 Option Settings
6.4.1 Introduction
The microprocessor communicates with a large number of I
2
C
ICs in the set. To ensure good communication and to make
digital diagnosis possible, the microprocessor has to know
which ICs to address. The presence / absence of these
MT5561 ICs is made known by the option codes.
Notes:
• After changing the option(s), save them by pressing the OK
button on the RC before the cursor is moved to the left,
select STORE and press OK on the RC.
• The new option setting is only active after the TV is
switched “off” / “stand-by” and “on” again with the mains
switch (the NVM is then read again).
6.4.2 Option Code Overview
Enter SAM mode to check the option codes. they could be
edited in the NVM.
6.4.3 Display Code Overview
Press the following key sequence on a standard RC
transmitter: “062598” directly followed by MENU and “xxx”,
where “xxx” is a 3 digit decimal value of the panel type: see
column “Display Code” in Table 6-3
. After resetting the Display
Code, restart the set immediately.
Table 6-3 Display code overview
6.5 Reset of Repaired SSB
A very important issue towards a repaired SSB from a Service
repair shop (SSB repair on component level) implies the reset
of the NVM on the SSB.
A repaired SSB in Service should get the service Set type
“00PF0000000000” and Production code “00000000000000”.
Cool (11000K) 22PFS4031/12 62 87 126
22PFT4031/05 65 90 125
22PFT4031/12 62 88 128
22PFT4031/60 63 89 128
24PHS4031/12 74 80 128
24PHT4031/05 72 82 125
24PHT4031/12 75 81 127
24PHT4031/60 73 79 128
24PFS5231/12 106 106 128
32PFS4131/12 116 119 128
32PFT4131/05 114 115 125
32PFT4131/12 116 118 126
32PHS4131/12 117 120 128
32PHT4131/05 116 119 127
32PHT4131/12 115 118 128
43PFS4131/12 100 112 128
43PFT4131/05 101 113 127
43PFT4131/12 102 112 128
49PFS4131/12 115 123 125
49PFT4131/05 117 122 126
Warm (6500K) 22PFS4031/12 120 128 121
22PFT4031/05 120 128 121
22PFT4031/12 121 127 122
22PFT4031/60 121 127 120
24PHS4031/12 128 114 125
24PHT4031/05 128 114 125
24PHT4031/12 128 114 123
24PHT4031/60 127 112 124
24PFS5231/12 126 113 104
32PFS4131/12 127 115 75
32PFT4131/05 128 119 77
32PFT4131/12 125 116 75
32PHS4131/12 126 118 78
32PHT4131/05 127 119 77
32PHT4131/12 128 119 76
43PFS4131/12 128 124 96
43PFT4131/05 127 123 95
43PFT4131/12 127 121 95
49PFS4131/12 127 122 77
49PFT4131/05 126 122 76
Picture mode Screen size
Colour temperature
Red Green Blue
CTN_ALT BOM# Panel Type Display Code
22PFS4031/12 TPM215HW01-HGEL02 C3D 008
22PFS4031/12 TPM215WF1-WU3101.K 485BC 014
22PFS4031/12 TPM215HW01-HGEL02 C5A 020
22PFT4031/05 TPM215HW01-HGEL02 C3D 008
22PFT4031/05 TPM215WF1-WU3101.K 485BC 014
22PFT4031/05 TPM215HW01-HGEL02 C5A 020
22PFT4031/12 TPM215HW01-HGEL02 C3D 008
22PFT4031/12 TPM215WF1-WU3101.K 485BC 014
22PFT4031/12 TPM215HW01-HGEL02 C5A 020
22PFT4031/60 TPM215HW01-HGEL02 C3D 008
22PFT4031/60 TPM215WF1-WU3101.K 485BC 014
22PFT4031/60 TPM215HW01-HGEL02 C5A 020
24PHS4031/12 TPM236WH2-WHBN00.K 5943 009
24PHS4031/12 TPM236WH2-WHBN00.K 5853 011
24PHT4031/05 TPM236WH2-WHBN00.K 5943 009
24PHT4031/05 TPM236WH2-WHBN00.K 5853 011
24PHT4031/12 TPM236WH2-WHBN00.K 5943 009
24PHT4031/12 TPM236WH2-WHBN00.K 5853 011
24PHT4031/60 TPM236WH2-WHBN00.K 5943 009
24PHT4031/60 TPM236WH2-WHBN00.K 5853 011
24PFS5231/12 TPM236WF1-HJJP02.N SC4M 010
32PFS4131/12 TPT315B5-FHBN0.K S49P2F 005
32PFT4131/05 TPT315B5-FHBN0.K S49P2F 005
32PFT4131/12 TPT315B5-FHBN0.K S49P2F 005
32PFT4131/12 TPT315B5-HVN05.A S601A 018
32PHS4131/12 TPT315B5-WHBN0.K S8940A 004
32PHS4131/12 TPT315B5-WHBN0.K S8940J 012
32PHS4131/12 TPT315B5-WHBN0.K S8D62D 015
32PHS4131/12 TPT315B5-DXYSHA.G S3A 017
32PHS4131/12 TPT315B5-DXYSGA.G S6A 019
32PHT4131/05 TPT315B5-WHBN0.K S8940A 004
32PHT4131/05 TPT315B5-WHBN0.K S8940J 012
32PHT4131/05 TPT315B5-WHBN0.K S8D62D 015
32PHT4131/05 TPT315B5-DXYSHA.G S3A 017
32PHT4131/05 TPT315B5-DXYSGA.G S6A 019
32PHT4131/12 TPT315B5-FHBN0.K S49P2F 004
32PHT4131/12 TPT315B5-WHBN0.K S8940J 012
32PHT4131/12 TPT315B5-WHBN0.K S8D62D 015
32PHT4131/12 TPT315B5-DXYSHA.G S3A 017
32PHT4131/12 TPT315B5-DXYSGA.G S6A 019
43PFS4131/12 TPT430H3-DUYSHA.G S1AM 006
43PFT4131/05 TPT430H3-DUYSHA.G S1AM 006
43PFT4131/12 TPT430H3-DUYSHA.G S1AM 006
49PFS4131/12 TPT490F2-FHBN0.K S8940J 007
49PFS4131/12 TPT490F2-FHBN0.K S8940G 016
49PFS4131/12 TPT490F2-FHBN0.K S8940Q 021
49PFT4131/05 TPT490F2-FHBN0.K S8940J 007
49PFT4131/05 TPT490F2-FHBN0.K S8940G 016
49PFT4131/05 TPT490F2-FHBN0.K S8940Q 021
