Circuit Descriptions
EN 35TPN16.3E LA 7.
2016-Oct-28
back to
div. table
7.3.1 Power layout SSB
Figure 7-4 Power SSB Top View
20210_203.eps
U203, +3V3_Tuner
L703, +5V_STB
C626 PVDD(12V)
L701, DV11
C764, Panel_VCC
L704,DV33
U102, VCC_CI
