Philips 32PHS4131/12 User Manual

EN 76TPN16.3E LA 10.
Circuit Diagrams and PWB Layouts
2016-Oct-28
back to
div.table
10.6 J 715G5964 IR/LED Panel
10-6-1 IR&LED Panel
19790_517.eps
IR&LED panel
J J
715G5964
IR&LED panel
IR
LED_B
LED_R
LED_BLED_R
VCC
VCC
RB
R3
NC/0R05 OHM
R3
NC/0R05 OHM
R6
4K7 1/16W 5%
R6
C2
100N 16V
C2 C3
100N 16V
C3
R1
15K 1/16W 5%
R1
Q1
BC847C
Q1
CN1
CONN
CN1
CONN
1
2
3
4
5
67
Q2
BC847C
Q2
R4
NC/0R05 OHM
R4
NC/0R05 OHM
Bl ueRed
LED1
12-22/BHR6C-C31/2C
Bl ueRed
LED1
1
2
3
R8
10K 1/16 5%W
U1
IRM-V836M3/TR1
U1
I
GND
1
VCC
2
Vout
3
GND
4
R5
4K7 1/16W 5%
R5
W
1K5 1/16 W 5%
R2
R7
10K 1/16 W 5%
R7
C1
2.2uF 10V
C1
2.2uF 10V
