LEGEND

Specification Desc./Quantity

1 Voltage regulator

2 Horn button

3 Turn signal switch

4 Light switch

5 Rear brake stop button

6 Front L.H. turn signal light

7 Front headlight

8 Two rear parking light bulbs 12V - 3W

9 Horn

10 Light bulb 12V - 35W for high-beam lamp

11 Light bulb 12V - 35W for low-beam lamp

12 Front R.H. turn signal light

13 Front brake stop light switch

14 Wheel rpm sensor

15 Starter button

16 Ignition key-switch

17 Fuel level sender

Electrical system NRG Power DT

ELE SYS - 2
