PIAGGIO NRG Power DT User Manual

Splitting the crankcase halves
Remove the eight crankcase union fasteners.
Install the special strip on the half crankcase on
the flywheel side and separate the half crankcase
on the flywheel side from the transmission side
Specific tooling
020163Y Crankcase splitting plate
Removing the crankshaft
- Install the specific tool on the half crankcase on
the transmission side using four M6 screws of an
adequate length.
- Remove the crankshaft from the transmission
side half crankcase
Specific tooling
020163Y Crankcase splitting plate
Engine NRG Power DT
ENG - 26
