PIAGGIO NRG Power DT User Manual

Refitting
When refitting, tighten to the prescribed torque and
apply the recommended grease to the threaded
cone.
Recommended products
AGIP GREASE PV2 Grease for control levers
on the engine
White anhydrous-calcium based grease to protect
roller bearings; temperature range between -20 °
C and +120 °C; NLGI 2; ISO-L-XBCIB2
Locking torques (N*m)
Locking torque: 65 to 70 N•m
Front fork
Removal
- Remove the front brake calliper.
- Remove the odometer cable from the reduction
gear box.
- Remove the front mudguard.
- Remove the handlebar.
After removing the steering ring-nut using the spe-
cial tool, lean the vehicle on one side and extract
the steering tube.
Specific tooling
020055Y Wrench for steering tube ring nut
See also
Front brake calliper
Handlebar
Overhaul
Replacing the seal ring
NRG Power DT Suspensions
SUSP - 3

PIAGGIO NRG Power DT Specifications

General

Engine Type	Single cylinder, 2-stroke
Fuel System	Carburetor
Ignition	Electronic
Front Suspension	Telescopic fork
Rear Suspension	Single shock absorber
Front Brake	Disc
Rear Brake	Drum
Dry Weight	92 kg
Top Speed	45 km/h
Transmission	Automatic
Front Tire	120/70-13
Rear Tire	130/60-13
