12. ELECTRICAL PARTS LIST
CONTRAST OF PCB ASSEMBLIES
XWK3363 and XWK3359 are constructed the same except for the following:
Parts marked by "NSP" are generally unavailable because they are not in our Master Spare Parts List.
The mark found on some component parts indicates the importance of the safety factor of the part.
Therefore, when replacing, be sure to use parts of identical designation.
When ordering resistors, first convert resistance values into code form as shown in the following examples.
Ex.1 When there are 2 effective digits (any digit apart from 0), such as 560 ohm and 47k ohm (tolerance is shown by J=5%,
and K=10%).
Ex.2 When there are 3 effective digits (such as in high precision metal film resistors).
561
473
R50
1R0
5621
NOTES:
560
Ω
47k Ω
0.5 Ω
1 Ω
RD1/4PU J
RD1/4PU J
RN2H K
RS1P K
56 x 10
1
47 x 10
3
R50
1R0
561
473
5.62k Ω RN1/4PC F562 x 10
1
5621
Meaning of the figures and others in the parentheses in the parts list.
Example) IC 301 is on the point (face A, 91 of x-axis, and 111 of y-axis) of the corresponding
PC board.
IC 301 (A, 91, 111) IC NJM2068V
Mark No. Description Part No.
LIST OF ASSEMBLIES
1..MAIN ASSY (VSX-918V) XWK3363
1..MAIN ASSY (VSX-818V) XWK3359
1..HDMI & DSP & USB ASSY AWX8977
(VSX-918V)
1..HDMI ASSY (VSX-818V) AWX8966
1..DSP & USB ASSY (VSX-818V) AWX9164
NSP 1..AMP ASSY XWK3349
2..POWER PACK ASSY XWZ4326
2..TRANS2 ASSY XWZ4335
2..TRANS3 ASSY XWZ4337
2..COMPONENT VIDEO ASSY XWZ4339
2..5.1CH INPUT ASSY XWZ4341
2..BIND ASSY XWZ4344
NSP 1..COMPLEX ASSY (VSX-918V) XWK3341
NSP 1..COMPLEX ASSY (VSX-818V) XWK3336
2..FRONT DISPLAY ASSY XWZ4285
(VSX-918V)
2..FRONT DISPLAY ASSY XWZ4284
(VSX-818V)
2..ROTARY ENCODER ASSY XWZ4286
2..POWER KEY ASSY (VSX-918V)XWZ4288
2..POWER KEY ASSY (VSX-818V)XWZ4287
2..JOG ASSY XWZ4289
2..VIDEO ASSY (VSX-918V) XWZ4294
2..VIDEO ASSY (VSX-818V) XWZ4292
2..DIGITAL INPUT ASSY XWZ4299
2..FRONT VIDEO ASSY XWZ4300
2..PRIMARY ASSY XWZ4302
2..REGULATOR ASSY XWZ4317
2..HEAD PHONE ASSY XWZ4321
1..FRONT IN ASSY XWK3366
1..FM/AM TUNER UNIT AXX7170
Mark No. Description Part No.
A
MAIN ASSY
Mark Symbol and Description XWK3363 XWK3359
IC9001 PEG469A8 PEG467A8
D9067 1SS355 Not used
CN130 13P FFC Connector Not used 9604S-13C
CN104 7P FFC Connector Not used 9604S-07C
CN112 FFC Connector 9604S-35C CKS3392
CN129 19P FFC Connector 9604S-19C Not used
R9024, R9063 RS1/16S103J Not used
R9025 RS1/16S332J RS1/16S562J
R9026 Not used RS1/16S103J
R9027, R9029 RS1/16S221J Not used
R9097 Not used RS1/16S0R0J
R9098 RS1/16S0R0J Not used
