Pioneer VSX-918V-K User Manual

16
VSX-918V-K
1
2 3 4
A
B
C
D
E
F
1
2 3 4
4. BLOCK BIAGRAM
4.1 OVERALL WIRING CONNECTION DIAGRAM (VSX-918V)
5/280
35/320
9/100
4/300
19/170
7/190
11/120
11/200
*7
3/300
1912
XDD3248
CN5
5
CN805
CN1
21
13 21
CN816
CN111
21
CN2
CN806
CN815
15
CN109
15
CN704 CN110
17
17
XDD3249
35
CN3
1917
9
CN122
35
CN112
CN401
CN101CN107
XDD3247
1906
XDX3063
1904
3/350
1902
CN956
CN953
CN951
17/110
CN901
1905
1908
CN105
CN129
7
19
XDD3253
CN803 CN302
6
CN1903
CN103
11
1911
1919
XDD3189
XDD3235
CN303
CN310
CN354
CN307
CN701
CN252
810
XDX3066
J43
CN702
CN251
CN800
2/500
XDX3054
511
J42
5/125
D15A05-125-2651
XDD3200
XDX3064
CN401
404
J22
E.g. 7/140
140: Insulation length (mm)
7: Number of contacts (pin)
WIRE INDICATION
XXM3012
FAN
A 1/3 - A 3/3
A
FRONT DISPLAY ASSY
(VSX-918V:XWZ4285)
H
T
F
P
DIGITAL
INPUT ASSY
(XWZ4299)
5.1CH
INPUT ASSY
(XWZ4341)
M
N
MAIN ASSY
(VSX-918V : XWK3363)
VIDEO ASSY
(VSX-918V : XWZ4294)
POWER PACK
ASSY
(XWZ4326)
REGULATOR
ASSY
(XWZ4317)
FRONT IN ASSY
(XWK3366)
HDMI&DSP&USB ASSY (VSX-918V:AWX8977)
C 1/2 -
C 2/2
C
ROTARY
ENCODER
ASSY
(XWZ4286)
I
FRONT VIDEO
ASSY
(XWZ4300)
R
FM/AM TUNER UNIT (AXX7170)
(Note :
No schematic diagram)
V 1/5 - V 5/5
V

Pioneer VSX-918V-K Specifications

General

Impedance	8 Ω
RMS rated power	130 W
Audio output channels	5.1 channels
Signal-to-Noise Ratio (SNR)	88 dB
Frequency band	0.005 — 100 GHz
Dimensions (WxDxH)	420 x 352.5 x 158 mm
Power requirements	220 — 230 V, 50/60 Hz
Connectivity technology	Wired
Headphone outputs	1
Product color	Black
Power consumption (standby)	0.5 W
Power consumption (typical)	290 W

Weight and Dimensions

Weight	8100 g
