XWZ4285 and XWZ4284 are constructed the same except for the following:
XWZ4288 and XWZ4287 are constructed the same except for the following:
XWZ4294 and XWZ4292 are constructed the same except for the following:
PCB PARTS LIST FOR VSX-918V/MYSXJ5 UNLESS OTHER WISE NOTED
H
FRONT DISPLAY ASSY
Mark Symbol and Description XWZ4285 XWZ4284
Q441 RT1N241M Not used
D404, D405 1SS355 Not used
D502 SLR343BC4T(JKLM) Not used
R404 RS1/16S472J Not used
R430 Not used RS1/16S0R0J
R551 RS1/16S391J Not used
J
POWER KEY ASSY
Mark Symbol and Description XWZ4288 XWZ4287
D501 SLR343BC4T(JKLM) Not used
R501 RS1/16S391J Not used
P
VIDEO ASSY
Mark Symbol and Description XWZ4294 XWZ4292
L302-L306 Chip Solid Inductor QTL1013 Not used
CN303 Connector 9604S-19C Not used
CN304 13P FFC Connector Not used 9604S-13C
JA351 Mini Jack(4P) /W SW XKN3015 Not used
JA352 Jack VKB1243 Not used
R394 RS1/16S0R0J Not used
C379 CKSRYB103K50 Not used
Mark No. Description Part No.
COMPLEX ASSY
MISCELLANEOUS
J 41 JUMPER WIRE D15A03-100-2651
J 42 JUMPER WIRE D15A05-125-2651
J 44 JUMPER WIRE D15A03-100-2651
A
MAIN ASSY
MISCELLANEOUS
IC 103 (A,215,73) DUAL OP-AMP NJM4565MD
IC 104 (A,198,56) DUAL OP-AMP NJM4565MD
IC 105 (A,217,87) DUAL OP-AMP NJM4565MD
IC 108 (B,253,65) 6CH E-VOL IC BD3474KS2
IC 251 (A,134,89) DUAL OP-AMP NJM4565MD
IC 5001 (A,69,19) RDS DECORDER IC LC72725KM
IC 6001 (A,135,20) IC TC74VHCT125AFTS1
IC 9001 (B,82,64) SYSTEM CONTROL MICON PEG469A8
IC 9002 (A,104,42) EEPROM BR24L16FV-W
IC 9004 (A,128,49) LOGIC IC TC4094BFN
Q 248 (A,53,103) TRANSISTOR 2SC4081
Q 249 (A,61,107) TRANSISTOR RT1N241M
Q 250 (A,60,112) TRANSISTOR 2SC4081
Q 252 (A,65,105) TRANSISTOR 2SD1858X
Q 253 (A,53,99) TRANSISTOR RT1N241M
Q 254 (B,61,103) DIGITAL TR(SC-70) RT1P241M
Q 255 (A,61,99) TRANSISTOR 2SC4081
Q 256 (A,61,95) CHIP TRANSISTOR 2SD2704K
Q 257 (A,76,112) TRANSISTOR 2SA1576A
Q 259 (B,61,108) DIGITAL TR(SC-70) RT1P241M
Q 260 (A,56,107) TRANSISTOR 2SC4081
Q 361 (A,181,72) TRANSISTOR 2SC5938A
Q 6001 (A,140,24) TRANSISTOR RT1N241M
Q 9001 (A,91,94) DIGITAL TR(SC-70) RT1N431M
Q 9002 (A,66,80) DIGITAL TR(SC-70) RT1P241M
Q 9003 (A,65,75) DIGITAL TR(SC-70) RT1P241M
Q 9007 (A,69,85) TRANSISTOR DTC143TK
Q 9064 (A,59,80) DIGITAL TR(SC-70) RT1P241M
Q 9065 (A,55,78) TRANSISTOR UMD2N
D 103 (B,177,35) DIODE DAN217U
D 105 (B,170,35) DIODE DAN217U
D 107 (B,174,37) DIODE DAN217U
D 251 (A,138,88) DIODE DAN217U
D 253 (B,55,108) DIODE UDZS13(B)
D 254 (A,72,113) DIODE UDZS5R1(B)
D 255 (B,53,109) DIODE UDZS13(B)
D 311 (B,258,96) DIODE 1SS355
D 312 (B,269,98) DIODE 1SS355
D 331 (B,254,91) DIODE UDZS6R8(B)
D 332 (B,271,91) DIODE UDZS6R8(B)
D 6001 (A,146,21) DIODE 1SS355
D 9006 (B,99,89) DIODE DAN217U
D 9007 (B,91,89) DIODE DAN217U
Mark No. Description Part No.

Pioneer VSX-918V-K Specifications

General

Impedance	8 Ω
RMS rated power	130 W
Audio output channels	5.1 channels
Signal-to-Noise Ratio (SNR)	88 dB
Frequency band	0.005 — 100 GHz
Dimensions (WxDxH)	420 x 352.5 x 158 mm
Power requirements	220 — 230 V, 50/60 Hz
Connectivity technology	Wired
Headphone outputs	1
Product color	Black
Power consumption (standby)	0.5 W
Power consumption (typical)	290 W

Weight and Dimensions

Weight	8100 g
