Pioneer VSX-918V-K User Manual

86
VSX-918V-K
1
2 3 4
A
B
C
D
E
F
1
2 3 4
10.12 DIGITAL INPUT, REGULATOR and HEAD PHONE ASSYS
5
3
4
2
132
1
2
2
1
1
132
5
3
4
6
5
8
37
4
9
132
10
STBY
TO FRONT IN ASSY
STBY
SHEILD
D+5V
GNDD
SHEILD
OPT1
V+5D
FRONT OPT
GNDD
OPT3
GNDD
GNDD
OPT2
GNDD
TO DSP+USB MODULE(818,518/J) TO DSP+HDMI+USB MODULE(918)
(DIGITAL IN BLOCK)
OPT_OUT
GNDD
NOTE
1.RESISTORS
2.CAPACITORS
Tolerance: (J) 5% unless otherwise noted.
Unit: p-pF or μF unless otherwise noted.
Ratings: Capacity(μF)/Voltage(V) unless otherwise noted.
Unit: k-kΩ, M-MΩ or Ω unless otherwise noted.
Rated power: 1/16W unless otherwise noted.
Rated Voltage: 50V expect for electrolytic capacitors.
-
+
KN1902
KN1901
C1906
C1905
JA1902
JA1901
JA1900
C1907
C1908
C1904
C1903
R1904
F1901
R1903
C1902
R1902
C1909
CN1902
C1901
R1901
CN1903
C1900
R1900
CN1904
VNE1948-A
CHASSIS
STBY
YB0.1
GP1FAV51TK0F
GP1FAV51RKBF
GP1FAV51RKBF
100p
0.01
CH
1000p
YB
CH
0.1
YB
CEAL-TS
100/10
0.01
STBY
YB
CTF1295
STBY
100
B5B-PH-K-S
STBY
0.1 YB
100
VKN1181
0.1 YB
100
STBY
DIGITAL INPUT ASSY
(XWZ4299)
M
CN5
V 1/5
CN5
B 1/4
M

Pioneer VSX-918V-K Specifications

General

Impedance	8 Ω
RMS rated power	130 W
Audio output channels	5.1 channels
Signal-to-Noise Ratio (SNR)	88 dB
Frequency band	0.005 — 100 GHz
Dimensions (WxDxH)	420 x 352.5 x 158 mm
Power requirements	220 — 230 V, 50/60 Hz
Connectivity technology	Wired
Headphone outputs	1
Product color	Black
Power consumption (standby)	0.5 W
Power consumption (typical)	290 W

Weight and Dimensions

Weight	8100 g
