9850060 R02 - 2020-2021 850 AXYS™ Long Track Snowmobile Service Manual
© Copyright Polaris Inc.
BATTERY REMOVAL
CAUTION
Hot exhaust system parts can cause burns. Allow
adequate time for the exhaust system to cool. Never
perform this procedure with the engine running.
1. Remove the right side panel.
2. Remove the two plastic rivets
q
securing the console
panel to the chassis.
3. Remove the plastic rivet
w
securing the fender to the
chassis.
4. Disconnect the black (negative) battery cable
e
first.
5. Disconnect the red (positive) cable
r
last.
6. Pull the fender away from the battery compartment to
gain better access.
7. Remove the Battery hold down strap
t
.
8. Remove the battery shield
y
.
9. Remove the battery from the battery bracket.
MAINTENANCE
