9850060 R02 - 2020-2021 850 AXYS™ Long Track Snowmobile Service Manual
© Copyright Polaris Inc.
RELAY / FUSE DETAILS
CIRCUIT PIN WIRE COLOR FUNCTION
Spare 5A Fuse
A1
— —
B1
— —
Spare 10A Fuse
C1
— —
D1
— —
Battery 6A Diode
D2 PK / WH
Gauge Battery Power
D3 PK / BK
Fused Battery Power
Battery Power
Gauge 6A Diode
C2 RD / BK
Critical Power - Gauge
C3 RD / BK
Fused Gauge Power
Battery Charge Relay
D4 RD Critical Power
C4 RD / WH Chassis Power
D5 RD / YE Chassis Power
C5 OG / DG
Battery Charge Relay Control
External PWR 6A Diode
D6 RD / DB External Power
D7 OG External Power
EV Learn Relay
D8 RD Critical Power
C8 RD Critical Power
D9 RD / BK
Brake Light Power
Gauge Test Power
C9 GY / YE
EV Actuator Relay Control
ECM Power 10A Fuse
B2 OG ECU Power
B3 RD / DB
Injector Power
Headlight 10A Fuse
B4 RD / BK
Fused Gauge Power
Fused Light Power
B5 Busbar EV Learn Load Center Bus
EV Control 5A Fuse
B6 RD / BK EV Actuator Power
B7 Busbar EV Learn Load Center Bus
Brake Light 2A Fuse
B8 RD / BK
Fused Brake Light Power
B9
RD / BK
Brake Light Power
Busbar EV Learn Load Center Bus
Rear Acc 10A Fuse
A2 RD / BU
Fused Passenger Power
A3
RD / WH Chassis Power
Busbar Chassis Load Center Bus
Accessory 10A Fuse
A4 RD / WH Fused Acc Power
A5 Busbar Chassis Load Center Bus
Drive Chassis 10A Fuse
A6 RD / WH Fused Drive Chassis Power
A7 Busbar Chassis Load Center Bus
Fan 10A Breaker
A8
— Not Applicable
A9
— Not Applicable
BATTERY / ELECTRICAL
