3.138
9850060 R02 - 2020-2021 850 AXYS™ Long Track Snowmobile Service Manual
© Copyright Polaris Inc.
9. Slide the springband clamps
t
down the coolant
hoses attached to the coolant bottle and disconnect
all the cooling hoses.
10.Carefully remove the coolant bottle.
NOTICE
If thermostat replacement is required, the coolant bottle
must be replaced.
COOLANT BOTTLE / THERMOSTAT
INSTALLATION
1. Carefully install the coolant bottle
2. Connect all the cooling hoses and slide the
springband clamps
q
down to secure the coolant
hoses.
3. Install the two plastic rivets
w
to secure the
connector placement bracket to the coolant bottle.
4. Install the two fasteners
e
securing the coolant bottle
to the footrest and torque fasteners to specification.
TORQUE
Coolant Bottle Bracket Fasteners:
7 ft-lbs (9 Nm)
5. Install the fuel tank.
ENGINE / COOLING / EXHAUST
