CLUTCH
6.5
PVT DISASSEMBLY
NOTE: Some fasteners andprocedures willvary. Refertotheappropriate partsmanualforproper fastenersand
fastener placement. (See page 6.8).
1. Remove seat.
2. Remove or loosen rear cab fasteners as necessary to
gain access to PVT outer cover.
3. Remove PVT air outlet duct hose.
4. Remove outer cover screws and clip. Refer to page
6.8.
5. Mark the drive belt direction of rotation and remove
drive belt. See page 6.19 for drive belt removal.
6. Remove drive clutch retaining bolt and remove drive
clutch using puller.
Drive Clutch Puller PN 2870506
