Quectel EC200T Series User Manual

LTE Standard Module Series
EC200T Series Hardware Design
EC200T_Series_Hardware_Design 19 / 90
3 Application Interfaces
3.1. General Description
EC200T series is equipped with 80 LCC pins plus 64 LGA pins that can be connected to cellular
application platform. The subsequent chapters will provide detailed descriptions of the following
interfaces.
 Power supply
 (U)SIM interface
 USB interface
 UART interfaces
 PCM and I2C interfaces
 SD card interface
 WLAN interface*
 ADC interfaces
 Status indication
 FORCE_USB_BOOT interface
“*” means under development.
