Quectel EC200T Series User Manual

LTE Standard Module Series
EC200T Series Hardware Design
EC200T_Series_Hardware_Design 81 / 90
LTE-FDD B1/B2/B3/B4/B5/B7/B8/B28 23 dBm ±2 dB < -39 dBm
LTE-TDD B40 23 dBm ±2 dB < -39 dBm
1. In GPRS 4 slots Tx mode, the maximum output power is reduced by 2.5 dB. The design conforms to
the GSM specification as described in Chapter 13.16 of 3GPP TS 51.010-1.
2. “*” means under development.
5.6. RF Receiving Sensitivity
The following table shows conducted RF receiving sensitivity of EC200T-CN module. And the data for
EC200T-EU and EC200T-AU* will be supplemented in subsequent versions of this document.
Table 40: EC200T-CN Conducted RF Receiving Sensitivity
Frequency
Receiving Sensitivity (Typ.)
3GPP (SIMO)
Primary Diversity SIMO
EGSM900 -108 dBm NA NA -102 dBm
DCS1800 -108 dBm NA NA -102 dBm
WCDMA B1 -108 dBm NA NA -106.7 dBm
WCDMA B5 -109 dBm NA NA -104.7 dBm
WCDMA B8 -110 dBm NA NA -103.7 dBm
LTE-FDD B1 (10 MHz) -97 dBm -98.5 dBm -100 dBm -96.3 dBm
LTE-FDD B3 (10 MHz) -97.5 dBm -97.5 dBm -100.5 dBm -93.3 dBm
LTE-FDD B5 (10 MHz) -98 dBm -99 dBm -101 dBm -94.3 dBm
LTE-FDD B8 (10 MHz) -98 dBm -98 dBm -101 dBm -93.3 dBm
LTE-TDD B34 (10 MHz) -96.5 dBm -97 dBm -100 dBm -96.3 dBm
LTE-TDD B38 (10 MHz) -97 dBm -97.5 dBm -100 dBm -96.3 dBm
NOTES
