PCS1900 PCL = 0 @ 30.16 dBm 220.2 mA
PCS1900 PCL = 7 @ 16.78 dBm 117.3 mA
PCS1900 PCL = 15 @ 1.63 dBm 97.5 mA
EGSM850 PCL = 5 @ 32.97 dBm 276.1 mA
EGSM850 PCL = 12 @ 19.79 dBm 128.5 mA
EGSM850 PCL = 19 @ 6.73 dBm 100.0 mA
WCDMA
voice call
WCDMA B1 @ 23.42 dBm 718.3 mA
WCDMA B2 @ 23.44 dBm 818.6 mA
WCDMA B4 @ 24.02 dBm 752.1 mA
WCDMA B5 @ 23.38 dBm 625.6 mA
WCDMA B8 @ 23.57 dBm 658.3 mA
备注
“*” means under development.
5.5. RF Output Power
The following table shows the RF output power of EC200T series module.
Table 37: EC200T-CN RF Output Power
Frequency Max. Min.
EGSM900 33 dBm ±2 dB 5 dBm ±5 dB
DCS1800 30 dBm ±2 dB 0 dBm ±5 dB
EGSM900 (8-PSK) 27 dBm ±3 dB 5 dBm ±5 dB
DCS1800 (8-PSK) 26 dBm ±3 dB 0 dBm ±5 dB
