Quectel EC200T Series User Manual

LTE Standard Module Series
EC200T Series Hardware Design
EC200T_Series_Hardware_Design 67 / 90
5.2. Power Supply Ratings
Table 32: The Module Power Supply Ratings
Parameter Description Conditions Min. Typ. Max. Unit
VBAT
VBAT_BB and
VBAT_RF
The actual input voltages
must be kept between the
minimum and maximum
values.
3.4 3.8 4.5 V
Voltage drop during
burst transmission
Maximum power control
level on EGSM900.
400 mV
I
VBAT
Peak supply current
(during transmission
slot)
Maximum power control
level on EGSM900.
1.8 2.0 A
USB_VBUS
USB connection
detection
3.0 5.0 5.25 V
5.3. Operating and Storage Temperatures
The operating and storage temperatures are listed in the following table.
Table 33: Operating and Storage Temperatures
Parameter Min. Typ. Max. Unit
Operation Temperature Range
1)
-35 +25 +75 ºC
Extended Operation Range
2)
-40 +85 ºC
Storage Temperature Range -40 +90 ºC
