EMCinstallationguidelines
R
aymarine®equipmentandaccessoriesconformtotheappropriateElectromagneticCompatibility
(EMC)regulations,tominimizeelectromagneticinterferencebetweenequipmentandminimizethe
effectsuchinterferencecouldhaveontheperformanceofyoursystem
CorrectinstallationisrequiredtoensurethatEMCperformanceisnotcompromised.
Note:
Inareasofe
xtremeEMCinterference,someslightinterferencemaybenoticed.Wherethisoccurs
theproductandthesourceoftheinterferenceshouldbeseparatedbyagreaterdistance.
ForoptimumEMCperformancewerecommendthatwhereverpossible:
•R aymarine®equipmentandcablesconnectedtoitare:
–Atleast1m(3ft)fromanyequipmenttransmittingorcablescarryingradiosignalse.g.VHFradios,
cablesandantennas.InthecaseofSSBradios,thedistanceshouldbeincreasedto2m(7ft).
–Morethan2m(7ft)fromthepathofaRadarbeam.ARadarbeamcannormallybeassumedto
spread20degreesaboveandbelowtheradiatingelement.
•Theproductissuppliedpowerfromaseparatebatteryfromthatusedforenginestart.Thisis
importanttopreventerraticbehavioranddatalosswhichcanoccuriftheenginestartdoesnot
haveaseparatebattery.
•OnlyRaymarine®specifiedcablesareused.
•Cablesarenotcutorextended,unlessdoingsoisdetailedintheinstallationinstructions.
Note:
Whereconstraintsontheinstallationpreventanyoftheaboverecommendations,alwaysensure
themaximumpossibleseparationbetweendifferentitemsofelectricalequipment,toprovidethe
bestconditionsforEMCperformancethroughouttheinstallation.
Suppressionferrites
•R aymarine®cablesmaybepre-fittedorsuppliedwithsuppressionferrites.Theseareimportantfor
correctEMCperformance.Ifferritesaresuppliedseparatelytothecables(i.e.notpre-fitted),you
mustfitthesuppliedferrites,usingthesuppliedinstructions.
•Ifaferritehastoberemovedforanypurpose(e.g.installationormaintenance),itmustbereplaced
intheoriginalpositionbeforetheproductisused.
•Useonlyferritesofthecorrecttype,suppliedbyRaymarine®oritsauthorizeddealers.
•Whereaninstallationrequiresmultipleferritestobeaddedtoacable,additionalcableclipsshould
beusedtopreventstressontheconnectorsduetotheextraweightoftheferrites.
Connectionstootherequipment
Requirementforferritesonnon-Raymarinecables.
IfyourproductistobeconnectedtootherequipmentusingacablenotsuppliedbyRaymarine,a
suppressionferriteMUSTalwaysbeattachedtotheendofthecablenearesttotheRaymarine
product.
RFinterference
Certainthird-partyexternalelectricalequipmentcancauseRadioFrequency(RF)interferencewith
GNSS(GPS),AISorVHFdevices,iftheexternalequipmentisnotadequatelyinsulatedandemits
excessivelevelsofelectromagneticinterference(EMI).
SomecommonexamplesofsuchexternalequipmentincludeLEDlighting(e.g.:navigationlights,
searchlightsandfloodlights,interiorandexteriorlights)andterrestrialTVtuners.
Tominimizeinterferencefromsuchequipment:
•KeepitasfarawayfromGNSS(GPS),AISorVHFproductsandtheirantennasaspossible.
•Ensurethatanypowercablesforexternalequipmentarenotentangledwiththepowerordata
cablesforthesedevices.
•ConsiderfittingoneormorehighfrequencysuppressionferritestotheEMI-emittingdevice.The
ferrite(s)shouldberatedtobeeffectiveintherange100MHzto2.5GHz,andshouldbefitted
tothepowercableandanyothercablesexitingtheEMI-emittingdevice,ascloseaspossibleto
thepositionwherethecableexitsthedevice.
Installation
21
