Raymarine AIS700 Installation Instructions

1.AISunit
2.USBMicro-BtotypeAcable(notsupplied)
3.PC(personalcomputer)runningproAIS2
Note:
•ThePCUSBconnectionwillprovidepowertotheunittoenableconfigurationpriortoinstallation.
•Fordetailsonconfiguringyourunit,referto:Chapter5Setup
Warning:USBdevicepower
DoNOTconnectanydevicetotheproduct’sUSBconnectionthatrequiresan
externalpowersource.
4.3P owerconnection
1.P ower/datacable(supplied)
2.Powersupply–(Negative)Blackwire
3.Powersupply+(Positive)Redwire
4.Suitablewaterproofconnection(notsupplied)
5.Powercableextensiontovessel’scircuitbreaker/powersource
6.Powersource(12/24Vdc)
