Raymarine AIS700 Installation Instructions

1.UsingtheAIS700asaguide ,markthelocationofthemountingholesonthemountingsurface.
2.Drillholesforthemountingfixingsusingadrillwithasuitablesizeddrillbit.
3.Screwthefixingsapproximatelyhalfwayintotheholesinthemountingsurface.
4.PlacetheAIS700overthefixingsscrewsandpushdowntolockintoposition.
5.Fullytightenthescrews.
6.Connectthenecessarycables.
3.3MountingtheGNSS(GPS)antenna
Tomounttheantenna:
1.Selectasuitablelocationfortheantenna,asdescribedinthe
GNSSantennalocation
requirements section.
2.Mountyourantennaaccordingtotheinstructionsprovidedinthefollowingdocument: 88092
GA200Installationinstructions .ThedocumentissuppliedwiththeGNSSantenna,andisalso
availabletodownloadfromtheRaymarinewebsite:www.raymarine.com/manuals
Important:IfyouarereplacingaGPSantennasuppliedwithanolderAISreceiveroranAIS700
withanearly(low)serialnumber ,pleasebeawarethatthemountingdiameter(cutout)oftheGPS
receiverhaschanged,fromØ44mmtoØ60mm.
Installation23
