4.1Partssupplied
Unpackyourproductcarefullytopreventdamageorlossofparts.Checkthe
boxcontentsagainstthelistbelow.Retainthepackaginganddocumentation
forfuturereference.
Thefollowingpartsaresuppliedinthebox.
Item
Description
1
No.10x3/4"selftappingscrewsx4(formountingthewind
transducer).
2
No.7x3/4"selftappingscrewsx2(formountingthegateway).
3
40mm(1.57in)heatshrinktube(requiredtoinsulateground
wirewhenshorteningthemastcable).
4
Ringcrimpterminal(requiredforadditionalgroundconnection
whenthegatewayisnotmountedonametalsurface).
5
Mastcable,30m(98.43ft)reel.
6
Documentation.
7
RSW-WiredSmartWindtransducer.
Item
Description
8NMEA2000Wiredgateway.
9
SeaTalkng®toDeviceNetadaptorcable,120mm(4.72in).
Additionalcomponents
Dependingoninstallationthefollowingadditionalcomponentsmaybe
required:
1.Suitablecableforgatewaygroundconnection.
2.M4x10machinescrewandM4nut(forgatewaygroundconnection
wheninstallationisfloating).
3.4xfixingssuitableforwindtransducermounting(ifsuppliedscrewsare
notsuitable).
4.2xfixingssuitableforgatewaymounting(ifsuppliedscrewsarenot
suitable).
5.Solderingironandsuitablesolder(requiredtore-tinmastcablewiresif
cut).
6.Cableclipsformastcable.
Partssupplied
17
