14.1Troubleshooting
Thetroubleshootingsectionprovidespossiblecausesandthecorrective
actionrequiredforcommonproblemsthatareassociatedwiththeinstallation
andoperationofyourproduct.
Beforepackingandshipping,allRaymarine®productsaresubjectedto
comprehensivetestingandqualityassuranceprograms.Ifyoudoexperience
problemswithyourproduct,thissectionwillhelpyoutodiagnoseandcorrect
problemstorestorenormaloperation.
Ifafterreferringtothissectionyouarestillhavingproblemswithyour
product,pleaserefertotheT echnicalsupportsectionofthismanualfor
usefullinksandRaymarine®ProductSupportcontactdetails.
14.2Winddatatroubleshooting
Note:
Wheresolutionsareprovidedinnumberedsteps,followthestepsinorder.
Dataappearsasdashesondisplay
PossiblecausesPossiblesolutions
Winddataissetto[True]windand
thereisnoSpeedThroughWater
(STW)dataavailable.
1.Setwinddatato[Apparent]and
checkforwinddata.
2.Ifwinddataappears,andyou
requireTruewindinstead,check
thesourceofSTWdata.
Windtransducerconnection
problem.
1.Checkcablingtoensureitis
freefromdamage.
2.Checkthecablejunctionbox
(usuallylocatedatthebottom
ofthemast)fordamageand
corrosion,andensurethat
connectionsarecleanand
secure.Repairandreplaceas
necessary.
3.Checkconnectionstodisplay
orconverterfordamageand
corrosion,andensurethat
connectionsarecleanand
secure.Repairandreplaceas
necessary.
4.Disconnectthewindvane
armandcheckarmandbase
connectorsfordamageand
corrosion.Ensurethattheyare
cleanandsecure,andrepair
andreplaceasnecessary.
Dataappearstobeincorrect
PossiblecausesPossiblesolutions
Windtransducerhasnotbeen
calibrated,orhaslostitscalibration
settings.
1.Re-calibratethewind
transducer.Refertothe
operationsinstructionssupplied
withyourdisplayforcalibration
procedures.
48
