7.1Toolsrequired
Thefollowingtoolsarerequiredforinstallation.
1.Cordlessdrill.
2.Pozi-drivescrewdriver.
3.SuitablesizeddrillbitformountingtheWindtransducer.
4.SuitablesizeddrillbitformountingtheGateway.
5.5mm(
13
⁄
64
in)drillbit(formastcablerouting).
6.Wirecutters.
7.3mmA/Fhexwrench(Allenkey)(forextratighteningofthumbscrew).
8.Pencilormarker.
Note:
Drillbitsizesformountingholesmustbeasuitablesizeforthefixings
andthematerialtypeandthicknessofthemountingsurface.(e.g.:a4mm
(
5
⁄
32
in)drillbitshouldbeusedwhenmountingthewindtransduceronan
aluminiumsurface).
7.2Mastcablerouting
Themastcablecanbeeitherroutedinsideoralongtheoutsideofthemast.
Whenroutingthecableinsidethemast,themastcableexitcanbelocated
underthemountingplate.Themountingplateincludesacablerecessfor
thispurpose.
Tokeepthesizeofanyholesthatneedtobedrilledforcableroutingtoa
minimum,routethemastcablefromthetransducerlocationusingthebare
wireendfirst.
•Ensuresufficientslackatthetransducerendsothatthewindtransducer
canbedisconnectedifnecessary
•Whendrillingroutingholesensuretheyarelargeenoughforthemast
cablewhichhasanapproximatelydiameterof5mm(0.20in).
•Thecableshouldbesecuredatregularintervalsusingcableclips.
•Excesscablecanbecutoncethecablehasbeenroutedtothegateway.
1.RSW-WiredSmartwindtransducer.
2.Cableroutingexternally.
3.Cableroutinginternally.
Installation23
