SpeedandTemperaturetransducers:
Partnumber
Description
E26008P371Thru-hull.
E26005ST69Transommount.
E26031ST800-P120Thru-hull.
M78716ST800-B120Thru-hull.
E70673
ST900-P120Thru-hull,with13.7m(44.95ft)fittedcable.
E70674
ST900-P120Thru-hull,with20m(65.62ft)fittedcable.
E70686
ST900-B120Thru-hull,with13.7m(44.95ft)fittedcable.
E70687
ST950-P17Thru-hullwith6m(19.69ft)fittedcable.
E25025
P17Thru-hull
17.5SeaTalkng®cablesandaccessories
SeaTalkng®cablesandaccessoriesforusewithcompatibleproducts.
SeaTalkng®kits
SeaTalkngkitsenableyoutocreateasimpleSea Talkngbackbone.
Starterkit(partnumber:T70134)consistsof:
1.1xSpurcable3m(9.8ft)(partnumber:A06040).Usedtoconnect
devicetotheSeaTalkngbackbone.
2.1xPowercable2m(6.6ft)(partnumber:A06049).Usedtoprovide
12VdcpowertotheSea Talkngbackbone.
3.2xBackboneterminators(partnumber:A06031).Terminatorsmustbe
fittedtobothendsoftheSeaTalkngbackbone.
4.1x5-Wayconnector(partnumber:A06064).Eachconnectorblock
allowsconnectionofupto3SeaTalkngdevices.Multipleconnector
blockscanbe‘daisychained’together.
Backbonekit(partnumber:A25062)consistsof:
1.2xBackbonecables5m(16.4ft)(partnumber:A06036).Usedtocreate
andextendtheSeaTalkngbackbone.
2.1xBackbonecable20m(65.6ft)(partnumber:A06037).Usedto
createandextendtheSeaTalkngbackbone.
3.4xT-piece(partnumber:A06028).EachT-pieceallowsconnectionof
oneSea Talkngdevice.MultipleT-piecescanbe‘daisychained’together.
