8-24 SL72 & SL72RC PLUS Pathfinder Radar & Radar/Chartplotter
Radar System Tests
and Post
Installation
Alignment
8.10 Radar System Tests and Post Installation Alignment
Once you have installed your Pathfinder Radar System and made all the
connections, you need to check your installation and perform the System Tests
before using the system for navigation. It is strongly recommended that the
System Tests are performed before connecting the radar to other equipment in
an integrated system. If you have extended your inter-unit cable, you will also
need to check the display timing. If you encounter any problems, refer to
Chapter 9.
You may wish to read Chapters 2 to 4, and familiarise yourself with the
operation of the system, before performing the initial set up and alignment.
System Check
Before performing the functional test, check the following:
• All securing bolts are fully tightened and mechanical locking arrange-
ments as specified are in place.
• Scanner and power connections have been made.
• All connecting wires are secured and protected as necessary.
Note: If you are the boat owner and have performed the installation yourself,
ask your authorised installation dealer to check the installation before going
to sea.
Switch On and Initial Setup
To switch on the display unit, press and hold the POWER key until the unit
beeps. The magnetron warm-up sequence should start, after which the unit
should enter Standby mode.
The display switches on in the last used mode. If it is necessary to change the
mode, press
DISPLAY to show the Display pop-up. Press DISPLAY again, as
necessary, to select Radar mode, then press
ENTER.
If necessary, adjust the lighting (see Changing the Lighting and Contrast on
page 2-6).
If required, change the default language settings as follows:
1. Press the
MENU key to display the setup soft keys.
2. Press the SYSTEM SET UP soft key.
The
SYSTEM SET UP menu is displayed, listing the parameters and their cur-
D3640-2
SYSTEM
SET UP¬
RADAR
SET UP¬
